DescriptionDefaultField Type or
Choices
Field
Allows you to select the type of authentication that
the phone uses to access the WLAN.
The security mode depends on the settings on your
access point.
NoneAuto
EAP-FAST
PEP-GCT
PEAP-MSCHAPV2
PSK
WEP
None
Security mode
Allows you to enter a unique name for the Wi-Fi
profile. This name displays on the phone.
Network name
Allows you to enter a user ID for the network
profile.
User ID
Allows you to enter password for the network
profile that you create. The type of password
depends on the security mode that you have
selected.
• Password: Security mode is Auto.
• Passphrase: Security mode is PSK.
• WEP Key: Security mode is WEP.
Password
WEP Key
Passphrase
Allows you to select the wireless signal standard
that the WLAN uses.
Auto• Auto
• 2.4 GHz
• 5 GHz
Frequency band
You can also configure Wi-Fi profile in the XML Configuration file in the format:
<!-- Wi-Fi Settings -->
<Phone-wifi-on ua="rw">Yes</Phone-wifi-on>
<Phone-wifi-type ua="na">WLAN</Phone-wifi-type>
<!-- available options: WLAN|WPS -->
<!-- Wi-Fi Profile 1 -->
<Network_Name_1_ ua="rw">wipp</Network_Name_1_>
<Security_Mode_1_ ua="rw">Auto</Security_Mode_1_>
<!--
available options: Auto|EAP-FAST|PEAP-GTC|PEAP-MSCHAPV2|PSK|WEP|None
-->
<Wi-Fi_User_ID_1_ ua="rw"></Wi-Fi_User_ID_1_>
<!--
<Wi-Fi_Password_1_ ua="rw">*************</Wi-Fi_Password_1_>
-->
<!-- <WEP_Key_1_ ua="rw"/> -->
<!--
<PSK_Passphrase_1_
ua="rw"/>
-->
<Frequency_Band_1_ ua="rw">Auto</Frequency_Band_1_>
<!-- available options: Auto|2.4 GHz|5 GHz -->
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
51
Phone Installation
Set Up a Wi-Fi Profile from the Phone Web Page and the XML Provisioning Server
