Cisco 7600 Series Guide

B-3
Cisco 7600 Series Router Supervisor Engine and Route Switch Processor Guide
OL-10100-04
Appendix B Cable and Connector Specifications
Uplink Port Transceiver Modules
1GE Uplink Ports and Cabling Specifications
Table B-2 describes the 1GE SFP transceiver modules that are used for Cisco 7600 uplink ports.
Table B-3 provides cabling specifications.
Note Use Category 5 Shielded Twisted Pair cable at the port that supports the10/100/1000-Mbps RJ-45
connector for the RSP720-10GE.
Supervisor Engine 32
10GE Uplink Ports (WS-SUP32-10GE-3B only):
XENPAK-10GB-CX4
XENPAK-10GB-SR
XENPAK-10GB-LX4
XENPAK-10GB-LR
XENPAK-10GB-ER
1GE Uplink Ports (WS-SUP32-GE-3B):
GLC-SX-MM
GLC-LH-SM
GLC-ZX-SM
GLC-T
Supervisor Engine 2 1000BASE-X GBIC modules, which are preinstalled
Table B-1 Uplink Port Transceiver Modules (continued)
Supervisor Engine or RSP Transceiver Module Part Numbers
Ta b l e B-2 1GE SFP Transceiver Modules
Product ID Description
Copper Modules
GLC-SX-MM 1000BASE-SX SFP transceiver module for multimode fiber
(MMF), 850-nm wavelength, LC connector
GLC-LH-SM 1000BASE-LX/LH SFP transceiver module for MMF and
single-mode fiber (SMF), 1300-nm wavelength, LC connector
GLC-ZX-SM 1000BASE-ZX SFP transceiver module for SMF,
1550-nm wavelength, LC connector
GLC-T 1000BASE-T SFP transceiver module for Category 5, 5e, or 6
copper wire; 10/100/1000-Mbps RJ-45 connector
GLC-BX-D 1000BASE-BX10 SFP module for single-strand SMF,
1490-nm TX/1310-nm RX wavelength (downstream use in
bidirectional single fiber applications), with Digital Optical
Monitoring (DOM), LC connector
GLC-BX-U 1000BASE-BX10 SFP module for single-strand SMF,
1310-nm TX/1490-nm RX wavelength (upstream use in
bidirectional single fiber applications), with DOM, LC
connector
Fiber Modules
