Continuing Configuration Using the Command-Line Interface
Configuring E1 R2 Signaling
8
Cisco AS5350XM and Cisco AS5400XM Universal Gateways Software Configuration Guide
Country Codes for R2 Signaling
Table 9 lists the country codes supported for R2 signaling.
.
Verify
To verify your R2 signaling configuration, enter the show controller e1 command to view the status for
all controllers, or enter the show controller e1 # command to view the status for a particular controller.
Make sure the status indicates the controller is up (line 2 in the following example) and no alarms (line
4 in the following example) or errors (lines 9 and 10 in the following example) have been reported.
AS5350# show controller e1 0/0
E1 0/0 is up.
Applique type is Channelized E1 - balanced
No alarms detected.
Version info of Slot 0: HW: 2, Firmware: 4, PLD Rev: 2
Manufacture Cookie is not programmed.
Framing is CRC4, Line Code is HDB3, Clock Source is Line Primary.
Data in current interval (785 seconds elapsed):
0 Line Code Violations, 0 Path Code Violations
0 Slip Secs, 0 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
Step 9
AS5350(config)# voice-port
slot/controller-number:DS0 group-number
AS5350(config-voiceport)#
Enters voice port mode for the port you want to
configure.
Step 10
AS5350(config-voiceport)# cptone
contry-code
Enters the 2-digit country code to configure the
regional ring tone.
Step 11
AS5350(config-voiceport)# Ctrl-Z
AS5350#
Returns to enable mode.
Command Purpose
Table 9 Country Codes for R2 Signaling
argentina greece paraguay
australia guatemala peru
bolivia hongkong-china philippines
brazil india saudiarabia
bulgaria indonesia singapore
china israel southafrica-panaftel
colombia itu telmex
costarica korea telnor
croatia laos thailand
easteurope malaysia uraguay
equador-itu malta venezuela
ecuador-lme newzealand vietnam
