PDN Gateway Overview

▀ Product Description

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

Figure 129. Basic E-UTRAN/EPC and eHRPD Network Topology

Internet

Enterprise

eAN/ePCF

A10/A11

SGi

eHRPD

S2a

Gxa

STa

E-UTRAN

EPC

S-GW

S1-U

S5/S8

S11

Gxc

S1-MME

eNodeB

S6a

MME

PCRF

3GPP

AAA

S6b

SWx

HSS

OFCS

S101

S103

HSGW

OCS

P-GW

Another key role of the P-GW is to act as the anchor for mobility between 3GPP and non-3GPP technologies such as

WiMAX and 3GPP2 (CDMA 1X and EvDO).

P-GW functions include:

Mobility anchor for mobility between 3GPP access systems and non-3GPP access systems. This is sometimes

referred to as the SAE Anchor function.

Policy enforcement (gating and rate enforcement)

Per-user based packet filtering (deep packet inspection)

Charging support
