Cisco ASR 5000 Series User Manual

Technical Specifications
▀ Physical Dimensions
▄ Cisco ASR 5000 Series Product Overview
OL-22938-02
Weight Specifications
An empty chassis, containing no PFUs, bezels, fan trays, or blanking panels, weighs 65 lbs. (29.48 kg). In its standard
shipping configuration, containing two power filter units, upper and lower fan trays, upper and lower bezels, and
blanking panels, the chassis weighs 160 lbs. (72.57 kg).
The total shipping weight, including wooden shipping container and packing materials, weighs 251 lbs. (113.85 kg).
The following table identifies the maximum weights for fully-loaded systems—cards installed in all slots and all other
components installed.
Table 102. Platform Fully Loaded Weight
Platform
Fully-loaded Weight
ASR 5000
307 lbs (139.25 kg)
Table 103. Individual Card Weights
Card
Weight
Packet Services Card (PSC)
11.50 lbs (5.22 kg)
Packet Services Card 2 (PSC2)
11.50 lbs (5.22 kg)
Packet Processing Card (PPC)
11.50 lbs (5.22 kg)
Redundancy Crossbar Card (RCC)
1.00 lbs (.45 kg)
Switch Process I/O Card (SPIO)
1.25 lbs (.57 kg)
System Management Card (SMC)
10.00 lbs (4.54 kg)
Line Cards
Channelized Line Card (CLC)
1.25 lbs (.57 kg)
Channelized Line Card 2 (CLC2)
1.25 lbs (.57 kg)
Fast Ethernet (10/100) Line Card (FELC)
1.00 lbs (.45 kg)
Gigabit Ethernet Line Card (GELC)
1.00 lbs (.45 kg)
Optical Line Card (OLC)
1.25 lbs (.57 kg)
Optical Line Card 2 (OLC2)
1.25 lbs (.57 kg)
Quad Gigabit Ethernet Line Card (QGLC)
1.25 lbs (.57 kg)
10 Gigabit Ethernet Line Card (XGLC)
2.25 lbs 1.02 kg)
