Session Control Manager Overview

▀ Product Description

▄ Cisco ASR 5000 Series Product Overview

OL-22938-02

Figure 144. IMS CSCF Components

BSC

PCF

Gateway

A10/A11

A8/A9

Application

Servers

P-CSCF

I-CSCF

S-CSCF

Home

Subscriber

Server

CSCFs

E-CSCF

LRF

In addition, the SCM may act as an Access Border Gateway (A-BG).

The following figure shows the general interaction between the A-BG and the supporting servers.
