Cisco ASR 9001 Installation Guide

Table 13: Subsystem Descriptions for the Cisco ASR 9000 Series Routers
DescriptionType of Subsystem
• Up to 8 AC input or DC input power supply modules can be installed in the
Cisco ASR 9010 Router chassis.
• Up to 4 AC input or DC input power supply modules installed in the Cisco
ASR 9006 Router chassis.
• Up to 6 AC input or DC input power supply modules installed in the Cisco
ASR 9904 Router chassis.
• Up to 3 AC input power supply modules or 4 DC input power supply
modules can be installed in the Cisco ASR 9906 Router chassis.
• Up to 6 AC input power supply modules or 8 DC input power supply
modules can be installed in the Cisco ASR 9910 Router chassis.
• Up to 12 AC input or DC input power supply modules installed in the Cisco
ASR 9912 Router chassis.
• Up to 16 AC input or DC input power supply modules installed in the Cisco
ASR 9922 Router chassis.
Power subsystem
The system transfers –54 VDC power from the power modules to the chassis
backplane and distributes it to all the cards through the backplane connectors.
Chassis backplane
power distribution
Processor subsystem
Includes the active Route Switch Processor (RSP) card (and optional, redundant
RSP card, if installed).
Up to eight line cards in the Cisco ASR 9010 Router and Cisco ASR 9910 Router,
four line cards in the Cisco ASR 9006 Router and Cisco ASR 9906 Router, and
two line cards in the Cisco ASR 9904 Router.
The RSP and line cards are equipped with onboard processors. The
RSP downloads a copy of the Cisco software image to each line card
processor. The system uses an alphanumeric display on the active RSP
to display status and error messages, which can help in troubleshooting.
Note
Cisco ASR 9010 Router
Cisco ASR 9006 Router
Cisco ASR 9904 Router
Cisco ASR 9906 Router
Cisco ASR 9910 Router
Includes the active Route Processor (RP) card, standby redundant RP card.
Up to 20 line cards in the Cisco ASR 9922 Router or 10 line cards in the Cisco
ASR 9912 Router.
The RP and line cards are equipped with onboard processors. The RP
downloads a copy of the Cisco software image to each line card
processor. The system uses an alphanumeric display on the active RP
to display status and error messages, which can help in troubleshooting.
Note
Cisco ASR 9922 Router
Cisco ASR 9912 Router
Cooling subsystem
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
198
Troubleshooting the Installation
Troubleshooting Using a Subsystem Approach
