NEW POWER SYSTEM:
power supply type: DC power supply version 2
chassis type: 10-slot
chassis bpid: 0x2fa, PID: ASR-9010-DC
UDI name: ASR-9010 DC, UDI desc: ASR-9010 DC
Step 4 Confirm your choice.
Example:
Please confirm that you wish to upgrade from AC power supply version 2 power system to
DC power supply version 2 power system by typing "yes" at the prompt below. Any other
response will cancel the power system change operation [yes/cancel]?
yes
Step 5 After the success message appears, power down the chassis.
Example:
start update CBC eeprom, offset = 0x0,length=1000
..............................................................
done update CBC eeprom
start update I2C eeprom
...............................................................
done update I2C eeprom
The power system programming change is complete. The system must now be completely powered
down, and the NEW power system hardware installed. When the system is rebooted the software
will recognize the new power system. Please power down the system at this point.
#
Step 6 Remove the old power module (see Removing a Version 1 AC or DC Power Module, on page 234 or Removing
a Version 2 or Version 3 AC or DC Power Module).
Use two hands to remove the power module. The power supply weighs about 6.5 pounds (2.95 kg).
Caution
Step 7 Install the new power module (see Installing a Version 1 AC or DC Power Module, on page 236 or Installing
a Version 2 or Version 3 AC or DC Power Module, on page 237).
To prevent damage to the power tray backplane connector, do not use excessive force when inserting
the power module into the power tray.
Caution
Step 8 Power up the chassis.
Step 9 Verify that the (green) Power Input indicator on the front of the power module goes on. If the indicator does
not light, see Troubleshooting the Power Subsystem.
Removing a Version 1 AC or DC Power Module
Follow these steps to remove a version 1 AC or DC power module from the power tray (figure below).
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
234
Replacing Cisco ASR 9000 Series Router Components
Removing a Version 1 AC or DC Power Module
