Connecting to SFP or SFP+ Modules
Connecting to Fiber-Optic SFP or SFP+ Modules
Class 1 laser product. Statement 1008
Warning
Do not remove the rubber plugs from the SFP or SFP+ module port or the rubber caps from the fiber-optic
cable until you are ready to connect the cable. The plugs and caps protect the SFP module ports and cables
from contamination and ambient light. Before connecting to the SFP module, be sure that you understand the
port and cabling stipulations.
Caution
Procedure
Step 1 Remove the rubber plugs from the module port and fiber-optic cable, and store them for future use.
Step 2 Insert one end of the fiber-optic cable into the SFP or SFP+ module port.
Step 3 Insert the other cable end into a fiber-optic receptacle on a target device.
Cisco Catalyst 1000 Series 24-Port and 48-Port Switch Hardware Installation Guide
30
Switch Installation
Connecting to SFP or SFP+ Modules
