Table 7: Materials for Mounting AP to a Wall with AIR-MNT-ART1= Kit
Supplied in the
Kit?
Materials Needed
YesGround lug and screws (provided with the access point)
YesPivoting mount kit and hardware
Yes(8) M6 x 12-mm Hex-head Bolts
YesAdapter bracket for option horizontal mount
YesTwo stainless steel band clamps (adjustable 2 to 5 inch (51 to 127 mm)
NoCrimping tool for ground lug, Panduit CT-720 with CD-720-1 die
NoFour wall mounting screws (6 mm max)
No#6 AWG ground wire
NoShielded outdoor-rated Ethernet (CAT5e or better) cable
NoGrounding block
NoGrounding rod
No13-mm box-end wrench or socket set
No10-mm box-end wrench
The mounting surface, attaching screws, and optional wall anchors to support a 50 lb (22.7 kg) static weight.
Caution
Procedure
Step 1 Disassemble the pivot kit, if not already disassembled.
Step 2 Use the mounting bracket's wall-plate end as a template to mark four screw hole locations on the mounting
surface. See Figure 58: Pivoting Wall Mounting Bracket , on page 49 for the mounting bracket screw hole
locations (screw holes of maximum 6 mm). See Figure 59: Pivoting Wall Mounting Bracket Dimensions, on
page 50 for the dimensions of the pivoting mounting bracket.
Step 3 Use four screws and, if required, wall anchors to attach the mounting bracket's wall-plate end to the mounting
surface. These screws and anchors are to be sourced independently.
• You can use an exterior-grade plywood backboard to mount the AP to stucco, cement, or
drywall.
• The mounting surface, attaching screws, and wall anchors must support a 50-lb (22.7 kg) static
weight. It is important to use proper anchoring for the mount surface to support the static load.
Note
Step 4 Align the AP-plate end of the bracket with the screw holes in the AP's back.
Cisco Catalyst 9124AX Series Outdoor Access Point Hardware Installation Guide
51
Installation Overview
Articulating Mount for the AP to a Wall or Ceiling
