A-2
Cisco Physical Security Multiservices Platform Series User Guide
OL-21838-03
Appendix A System Specifications
Power Supply Specifications
Power Supply Specifications
The following tables provide specifications for the about Multiservices Platform Series power supplies:
• Table A-2 provides power supply specifications for the Multiservices Platform Series 1-RU device
• Table A-3 provides power supply specifications for the Multiservices Platform Series 2-RU device
Power supply One 300 W internal power supply • One 900 W internal power supply
• (optional) One 900 W (1+1) redundant
internal power supply
Heat output 552 BTU/hour with four 1 TB hard drives 1,216 BTU/hour with twelve 2 TB hard
drives
On-board storage options • Minimum—One 1 TB hard drives:
approximately 874 GB (JBOD), for
video surveillance application
• Maximum—Four 1 TB hard drives:
approximately 2.58 TB (RAID-5), for
video surveillance application
One or two bundles of six 1 TB or 2 TB
hard-disk drives (Cisco part number
CPS-HDD-6TB-BNDL or
CPS-HDD-12TB-BNDL)
On-board storage repositories
options
• 1 in JBOD configuration for video
surveillance application
• 1 in RAID-5 configuration for video
surveillance application
1 in RAID-6 configuration for video
surveillance application
Operating temperature 50° to 95° F (10° to 35° C)
Non-operating temperature –40° to 158° F (–40° to 70° C)
Operating relative humidity 8% to 90% (non-condensing)
Non-operating relative humidity 5% to 95% (non-condensing)
Table A-1 Multiservices Platform Series General Specifications (continued)
Item 1-RU Multiservices Platform Series 2-RU Multiservices Platform Series
Ta b l e A-2 1-RU Multiservices Platform Series Model Power Supply Specifications
Power (W) Power Factor VA (W) Volts Amps
110 V/60 Hz
Idle 124.4 0.971 128.4 120 1.06
Spin up surge 170.0 0.978 173.8 120 1.44
220 V/60 Hz
Idle 122.3 0.864 142.2 220 0.65
Spin up surge 199.1 0.897 220.0 220 1.01
