Cisco Firepower 1120 Getting Started

Function
Destination Network
(Physical Interface Name)Source NetworkNetwork Adapter
DiagnosticDiagnostic0/0Diagnostic0-0Network adapter 2
Outside dataGigabitEthernet0/0GigabitEthernet0-0Network adapter 3
Inside dataGigabitEthernet0/1GigabitEthernet0-1Network adapter 4
Data trafficGigabitEthernet0/2GigabitEthernet0-2Network adapter 5
Data trafficGigabitEthernet0/3GigabitEthernet0-3Network adapter 6
Data trafficGigabitEthernet0/4GigabitEthernet0-4Network adapter 7
Data trafficGigabitEthernet0/5GigabitEthernet0-5Network adapter 8
Data trafficGigabitEthernet0/6GigabitEthernet0-6Network adapter 9
Data trafficGigabitEthernet0/7GigabitEthernet0-7Network adapter 10
Cabling for ISA 3000
Figure 5: ISA 3000
• Connect GigabitEthernet 1/1 to an outside router, and GigabitEthernet 1/2 to an inside router.
Getting Started
20
Getting Started
Cabling for ISA 3000

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
