Cisco Firepower 1120 Getting Started

Changes are not active on the device until you deploy them. See Deploying Your Changes, on page 35.
What to do next
Click Policies in the main menu and configure the security policy for the system. You can also click Objects
to configure the objects needed in those policies.
Configuring Security Policies
Use the security policies to implement your organization’s acceptable use policy and to protect your network
from intrusions and other threats.
Procedure
Step 1 Click Policies.
The Security Policies page shows the general flow of a connection through the system, and the order in which
security policies are applied.
Step 2 Click the name of a policy and configure it.
You might not need to configure each policy type, although you must always have an access control policy.
Following is a summary of the policies:
• SSL Decryption—If you want to inspect encrypted connections (such as HTTPS) for intrusions, malware,
and so forth, you must decrypt the connections. Use the SSL decryption policy to determine which
connections need to be decrypted. The system re-encrypts the connection after inspecting it. See
Configuring SSL Decryption Policies.
• Identity—If you want to correlate network activity to individual users, or control network access based
on user or user group membership, use the identity policy to determine the user associated with a given
source IP address. See Configuring Identity Policies.
• Security Intelligence—Use the Security Intelligence policy to quickly drop connections from or to
selected IP addresses or URLs. By blocking known bad sites, you do not need to account for them in
your access control policy. Cisco provides regularly updated feeds of known bad addresses and URLs
so that the Security Intelligence block lists update dynamically. Using feeds, you do not need to edit the
policy to add or remove items in the block lists. See Configuring Security Intelligence.
• NAT (Network Address Translation)—Use the NAT policy to convert internal IP addresses to externally
routeable addresses. See Configure NAT.
• Access Control—Use the access control policy to determine which connections are allowed on the
network. You can filter by security zone, IP address, protocol, port, application, URL, user or user group.
You also apply intrusion and file (malware) policies using access control rules. Use this policy to
implement URL filtering. See Configuring the Access Control Policy.
• Intrusion—Use the intrusion policies to inspect for known threats. Although you apply intrusion policies
using access control rules, you can edit the intrusion policies to selectively enable or disable specific
intrusion rules. See Intrusion Policies.
Getting Started
34
Getting Started
Configuring Security Policies

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
