Specifications
Linksys E1200.
Specifications
Linksys E1200
Model Name. Linksys E1200.
Description. Wireless-N Router.
Model Number. E1200.
Standards. 802.11n, 802.11g, 802.11b,
802.3u.
Ports. Power, Internet, and Ethernet (1-4).
Buttons. Reset, Wi-Fi Protected Setup™.
LEDs. Power/Wi-Fi Protected Setup,.
Internet, Ethernet (1-4).
Cabling Type. CAT 5e.
Transmitted Power. 802.11n (20 MHz):
15.0 ± 1.5dBm @ CH6, MCS 0~4, MCS 8~12.
13.5 ± 1.5dBm @ CH6, MCS 5~7, MCS 13~15.
802.11n (40 MHz):
14.0 ± 1.5dBm @ CH6, MCS 0~4, MCS 8~12.
13.5 ± 1.5dBm @ CH6, MCS 5~7, MCS 13~15.
802.11g:
14.5 ± 1.5dBm @ CH6, all rates.
802.11b:
16.5 ± 1.5dBm @ CH6, all rates.
Antenna Gain. ≤2.5 dBi, ≤4.0 dBi (2 antennas).
UPnP. Supported.
Wireless Security. Wi-Fi Protected Access™ 2 (WPA2),.
WEP, wireless MAC filtering.
Security Key Bits. Up to 128-bit encryption.
Environmental
Dimensions. 188.7 × 151.7 × 31.2 mm.
(7.43” × 5.97” × 1.23”).
Unit Weight. 252.7g (8.91 oz.).
Power. 12V, 0.5A.
Certifications. FCC, UL/cUL, ICES-003, RSS210,.
CE, Wi-Fi (IEEE 802.11b/g/n),
WPA2™, WMM®, Wi-Fi Protected.
Setup, Windows 7.
Operating Temp. 0 to 40°C (32 to 104°F).
Storage Temp. -20 to 60°C (-4 to 140°F)
Operating Humidity. 10 to 80% non-condensing.
Storage Humidity. 5 to 90% non-condensing.
NOTES
For regulatory, warranty, and safety information, see the CD that
came with your router or go to Linksys.com/support
Specifications are subject to change without notice.
Maximum performance derived from IEEE Standard 802.11
specifications Actual performance can vary, including lower
wireless network capacity, data throughput rate, range and
coverage Performance depends on many factors, conditions and
variables, including distance from the access point, volume of
network traffic, building materials and construction, operating
system used, mix of wireless products used, interference and other
adverse conditions.
