Specifications.
Linksys E4200.
Linksys E4200
Supported File Systems
for Storage Device. FAT32, NTFS, and HSF+
Model Name. Linksys E4200.
UPnP. Supported
Description. Maximum Performance Wireless-N Router.
Model Number. E4200.
Standards. 802.11n, 802.11a, 802.11g, 802.11b, 802.3,
802.3u, 802.3ab.
Radio Frequency. 2.4 and 5 GHz.
Switch Port Speed. 10/100/1000 Mbps (Gigabit Ethernet).
Ports. Power, USB, Internet, Ethernet (1-4).
Buttons. Reset, Wi-Fi Protected Setup.
LEDs. Top panel: Power.
Back panel: Internet, Ethernet (1-4).
Number of Antennas. 6 total, 3 internal antennas per
each 2.4 GHz and 5 GHz radio band.
Detachable (y/n). No.
Modulations. 802.11b: CCK, QPSK, BPSK.
802.11g: OFDM.
802.11a: OFDM.
802.11n: BPSK, QPSK, 16-QAM, 64-QAM.
Receive Sensitivity. 2.4 GHz.
802.11b: -87 dBm @ 11 Mbps (Typical).
802.11g: -77 dBm @ 54 Mbps (Typical).
802.11n: 20 MHz: -71 dBm @ MCS15 (Typical).
802.11n: 40 MHz: -68 dBm @ MCS15 (Typical).
5 GHz.
802.11a: -71 dBm @ 54 Mbps (Typical).
802.11n: 20 MHz: -70 dBm @ MCS23 (Typical).
802.11n: 40 MHz: -68 dBm @ MCS23 (Typical).
Antenna Gain in dBi. 2.4 GHz (3 internal PIFA antennas).
PIFA 1 ≤ 3.6 dBi (Right).
PIFA 2 ≤ 3.8 dBi (Left).
PIFA 3 ≤ 3.8 dBi (Front).
5 GHz (3 internal PIFA antennas).
PIFA 1 ≤ 4.8 dBi (Right).
PIFA 2 ≤ 5.3 dBi (Left).
PIFA 3 ≤ 5.2 dBi (Front).
Security Features. WEP, WPA, WPA2.
Security Key Bits. Up to 128-bit encryption.
Environmental
Dimensions. 225 x 25 x 160 mm
(8.86” x 0.98” x 6.30”).
Unit Weight. 355 g (12.52 oz).
Power. 12V, 2A.
Certifications. FCC, IC, CE, Wi-Fi a/b/g/n,
Windows.7.
Operating Temp. 0 to 40°C (32 to 104°F).
Storage Temp. -20 to 60°C (-4 to 140°F).
Operating Humidity. 10 to 80% relative humidity,
non-condensing.
Storage Humidity. 5 to 90% non-condensing.
NOTES
For regulatory, warranty, and safety information, see the CD that
came with your router or go to Linksys.com/support
Specifications are subject to change without notice.
Maximum performance derived from IEEE Standard 802.11
specifications Actual performance can vary, including lower
wireless network capacity, data throughput rate, range and
coverage Performance depends on many factors, conditions and
variables, including distance from the access point, volume of
network traffic, building materials and construction, operating
system used, mix of wireless products used, interference and other
adverse conditions.
21
