1-60
Cisco MDS 9148S Multilayer Switch Hardware Installation Guide
OL-20185-01
Chapter 1 Technical Specifications
SFP Transceiver Specifications
Environmental Conditions and Power Requirements for 8 Gbps
Table 1-10 provides the optical parameters for 8 Gbps.
Table 1-10 Optical Parameters for 8 Gbps
Table 1-11 provides information on operating and storage temperature ranges for 8 Gbps.
Optical Specifications for Cisco CWDM SFP Transceivers
Table 1-12 provides the optical specifications for CWDM SFP transceivers. CWDM SFP transceivers
have an optical link budget of 28 decibels (db).
Note The parameters are specified over temperature and at end of life unless otherwise noted.
SFP+ Average Transmit Power
(dBm)
Average Receive
Power (dBm)
Fiber Loss Budget (dB)
Max Min Max Min 62.5 microns
[OM1])
(50.0 microns
[OM2])
(50.0 microns
[OM3])
DS-SFP-FC8G-SW -1.3 -10 (2 Gbps)
-9 (4 Gbps)
-8.2 (8 Gbps)
0 — 2.10 (2 Gbps)
1.78 (4 Gbps)
1.58 (8 Gbps)
2.08 (4 Gbps)
1.68 (8 Gbps)
1.63 (16 Gbps)
3.31 (2 Gbps)
2.88 (4 Gbps)
2.04 (8 Gbps
DS-SFP-FC8 G-LW -3 (2 Gbps)
-1 (4 Gbps)
0.5 (8
Gbps)
-11.7 (2
Gbps)
-8.4 (4 Gbps)
-8.4 (8 Gbps
-3 (2 Gbps)
-1 (4 Gbps)
0.5 (8
Gbps)
— -7.8 (2 Gbps)
7.8 (4 Gbps)
6.4 (8 Gbps)
DS-SFP-FC8G-ER 4 -4.7 -1 — 10.9
Table 1-11 Operating and Storage Temperature Ranges for 8 Gbps
SFP+ Operating Storage
Max Min Max Min
DS-SFP-FC16G-SW 40°C 0°C 85°C -40°C
DS-SFP-FC16G-LW 40°C 0°C 85°C -40°C
