When installing an SFP or SFP+ module, you should hear a click as the triangular pin on the bottom of the SFP
module snaps into the hole in the receptacle, indicating that the module is correctly seated and secured in the
receptacle. Verify that the SFP modules are completely seated and secured in their assigned receptacles on the
line card by firmly pushing on each SFP module.
Note
Removing a Bale Clasp SFP or SFP+ Module
To remove this type of SFP or SFP+ module, follow these steps:
Step 1
Attach an ESD-preventive wrist or ankle strap and follow its instructions for use.
Step 2
Disconnect and remove all interface cables from the ports; note the current connections of the cables to the ports on the
line card.
Step 3
Open the bale clasp on the SFP module with your index finger, as shown in the figure below. If the bale clasp is obstructed
and you cannot use your index finger to open it, use a small flat-blade screwdriver or other long, narrow instrument to
open the bale clasp.
Step 4
Grasp the SFP module between your thumb and index finger and carefully remove it from the port, as shown in the figure
below.
Hardware Installation Guide for Cisco NCS 5500 Series Fixed-Port Routers
43
