Cisco SF 300-08 User Manual

Configuring IP Information
Domain Name Systems
Cisco Small Business 300 Series Managed Switch Administration Guide 191
15
To add a domain name and its IP address:
STEP 1 Click IP Configuration > Domain Name System > Host Mapping. The Host
Mapping Page opens.
This page displays the following fields:
• Host Name—User-defined domain name, up to 158 characters.
• IP Address—The host name IP address.
STEP 2 Click Add. The Add Host Mapping Page opens.
STEP 3 Enter the parameters.
• IP Version—Select Version 6 for IPv6 or Version 4 for IPv4.
• IPv6 Address Type—Select the IPv6 address type (if IPv6 is used). The
options are:
- Link Local—The IPv6 address uniquely identifies hosts on a single
network link. A link local address has a prefix of FE80, is not routable, and
can be used for communication only on the local network. Only one link
local address is supported. If a link local address exists on the interface,
this entry replaces the address in the configuration.
- Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
• Link Local Interface—If the IPv6 address type is Link Local, select whether
it is received through VLAN2 or ISATAP.
• Host Name—Enter a domain name, up to 158 characters.
• IP Address—Enter an IP v4 IP address or enter up to four IPv6 host IP
addresses. Addresses 2–4 are backup addresses.
STEP 4 Click Apply. The DNS host is added, and the switch is updated.

Cisco SF 300-08 Specifications

General

Brand	Cisco
Model	SF 300-08
Category	Switch
Language	English
