Cisco UCS 6400 Series User Manual

USB port4Network management port (RJ-45 connector)3
Power supplies
Two identical AC or DC PSUs, hot-swappable,
1+1 redundancy)
6Grounding pad for two-hole grounding lug
(under protective label)
5
Beacon LED8L1/L2 high-availabity ports (RJ-45 connector)7
--System status LED9
Ports on the Cisco UCS Fabric Interconnects
The ports on the fabric interconnects can be configured to carry either Ethernet or Fibre Channel traffic. You
can configure only ports 1-16 to carry Fibre Channel traffic. The ports cannot be used by a Cisco UCS domain
until you configure them.
When you configure a port on a Fabric Interconnect, the administrative state is automatically set to enabled.
If the port is connected to another device, this may cause traffic disruption. The port can be disabled and
enabled after it has been configured.
Note
The following table summarizes the Cisco UCS Fabric Interconnects.
Cisco UCS 6454 FI
54-Port Fabric InterconnectDescription
1-RUForm factor
48 10/25G interfacesNumber of fixed 10 GB Interfaces
16
This FI supported 8 unified ports (ports 1 - 8) with
Cisco UCS Manager 4.0(1) and 4.0(2), but with
Release 4.0(4) and later it supports 16 unified ports
(ports 1 - 16).
Number of Unified Ports
Ports 1-16Unified Port Range
10/25 Gbps or 8/16/32-Gbps FCUnified Port Speeds
6 40/100 Gigabit portsNumber of 40-Gbps ports
UCS 2204, UCS 2208, UCS 2408Compatibility with the IOM
Cisco Nexus 2232PP
Cisco Nexus 2232TM-E
Compatibility with the FEX
NoneExpansion Slots
Cisco UCS 6400 Series Fabric Interconnect Hardware Installation Guide
5
Product Overview
Ports on the Cisco UCS Fabric Interconnects
