Cisco UCS E Series User Manual

UCS-E160D-M2 and
UCS-E180D-M2Double-Wide E-Series
Servers
UCS-E140S M2 Single-Wide E-Series
Server
UCS-EN120S-M2 SM E-Series
NCE
Feature
2911 ISR G2—None
2921 ISR G2—1 E-Series Server
2951 ISR G2—1 E-Series Server
The Cisco 2921 and 2951
ISR G2 support 6 cores
only.
Note
3925 ISR G2—1 E-Series Servers
3925e ISR G2—1 E-Series Server
3945 ISR G2—1 E-Series Server
3945e ISR G2—1 E-Series Server
ISR 4321—None
ISR 4331—None
ISR 4351—1 E-Series Server
ISR 4431—None
ISR 4451-X—1 E-Series Server
2911 ISR G2—1 E-Series Server
2921 ISR G2—1 E-Series Server
2951 ISR G2—2 E-Series Servers
3925 ISR G2—2 E-Series Servers
3925e ISR G2—2 E-Series Servers
3945 ISR G2—4 E-Series Servers
3945e ISR G2—4 E-Series Servers
ISR 4321—None
ISR 4331—1 E-Series Server
ISR 4351—2 E-Series Servers
ISR 4431—None
ISR 4451-X—2 E-Series Servers
2911 ISR G2—1 NCE
2921 ISR G2—1 NCE
2951 ISR G2—2 NCEs
3925 ISR G2—2 NCEs
3925e ISR G2—2 NCEs
3945 ISR G2—4 NCEs
3945e ISR G2—4 NCEs
ISR 4321—None
ISR 4331—1 NCE
ISR 4351—2 NCEs
ISR 4431—None
ISR 4451-X—2 NCEs
Maximum
Number of
E-Series Servers
or NCE per
Router
3
All hardware drives within the E-Series Server must be installed with the same type of storage device: either all SAS drives or
all SATA drives.
4
The size of the HDD and SSD drives is expressed in decimal form. For instance, GB=1 billion bytes, not 2^30 bytes. TB=1
trillion bytes, not 2^40 bytes.
Hardware Information for the M3 E-Series Servers
Cisco UCS E Series M3 servers have a dedicated SSD flash disk based on eMMC technology. This eMMC
storage is not a user replaceable component. This replaces the SD card functionality that was used on M2.The
eMMC storage is used for hosting CIMC and is also available as a USB device to the x86 host side. On Cisco
UCS-E160S-M3 server, the size of the CIMC partition is 8 GB, and the size of the host partition is 8 GB.
Table 10: M3 E-Series Servers at a Glance
UCS-E1120D-M3 Double-Wide
E-Series Servers
UCS-E180D-M3 Double-Wide
E-Series Servers
UCS-E160S-M3 Single-Wide E-Series
Servers
Feature
Double-wide SMDouble-wide SMSingle-wide SMForm Factor
Intel Broadwell, 1.5 GHzIntel Broadwell, 2.0 GHzIntel Xeon Broadwell DE processor D-1528
(9-MB cache, 1.90 GHz, and 6 cores)
CPU
12-Cores with 1.5-GHz Clock
Speed
8-Cores with 2.0-GHz Clock
Speed
6-Cores with 1.90-GHz Clock SpeedCPU Cores and
CPU Clock Speed
Cisco UCS E-Series Servers and the Cisco UCS E-Series Network Compute Engine Hardware Installation Guide
8
Hardware Information for the M3 E-Series Servers

Cisco UCS E Series Specifications
