CBM-910 User’s Manual
CITIZEN 18
6. SERIAL INTERFACE
6.1 Specifications
(1) Synchronization : Asynchronous
(2) Baud rate : 1200, 2400, 4800, 9600 Baud/sec (User selection)
(3) Word configuration
•Start bit : 1 bit
•Data bit : 7 bit or 8 bit (User selection)
•Parity bit : odd, even, no parity (User selection)
•Stop bit : 1 bit or more
(4) Signal polarity
RS-232C
* Mark = Logic”1”(-3 to –12V)
* Space = Logic “0”(+3 to +12V)
TTL (RESET)
* H level = Logic”1”
* L level = Logic”0”
(5) Receive Data (RD)
* Mark : 1
* Space : 0
(6) Transmit Data (TD)
* Mark : 1
* Space : 0
(7) Received control (DTR signal)
* Mark : Data transmission not possible
* Space : Data transmission possible
