Citizen CL-S521 User Manual

10
Chapter 1 Setup
Chapter 1 Setup
Conrmation of Carton Contents
Removing the Packing Material
The printer is shipped with adhesive tape in place to hold the top cover
closed. Simply remove the two pieces of tape on either side of the top
cover. Then simply open the cover by lifting up and tipping it backwards.
There is another strip of adhesive tape that must be removed which holds
the mechanism closed for shipping. Remove the tape and attached
paper by carefully peeling from the plastic case.
Retain the tape should you need to transport the printer again.
CD-ROM
(User's Manual) Quick-start Guide
Printer
Media holder
bar
Media holder
guide
Head cleaner
Test label media
Power cord
CL-S521, CL-S621 & CL-S631
Thermal Transfer Barcode & Label Printer
Q
UICK-
S
TART
G
UIDE
This Quick-Start Guide covers basic operation.
For detailed operating instructions, please see the User's Manual on the
supplied CD-ROM.
CL-S521
CL-S621
CL-S631
Check that the following accessories are
included with the printer in the carton.
Note: The empty carton and packing materials should be stored for
future shipping of the printer.

Citizen CL-S521 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	183 mm
Weight	3600 g
