Names of parts
Status LED
The Bluetooth communication/connection/error status is indicated by this LED.
Switch
Control this interface board.
Bluetooth status LED
3.5 Bluetooth Interface Board
Status Description LED Status
Detection
standby
(Discoverable)
Standing by for
detection and
connection
Connection
standby
(Connectable)
Standing by for
connection
iOS connection Data session unopened
Communicating iOS: data session
opened
Other OS: connection
established and
communication in
progress
Error Error or settings being
configured
Unlit
