119
INJECTION
CHECKS : TURBO PRESSURE
Engine : 8HT
Tools.
[1] Pressure gauge for checking boost pressure : 4073-T.A
[2] Sleeve for checking boost pressure : (-).0171.F
[3] Manual pressure/vacuum pump : FACOM DA 16
[4] Pliers for removing clic clips : (-).0172.Z
IMPERATIVE : Respect the safety requirements.
Checks
IMPERATIVE : Respect the following test conditions:
- Engine at operating temperature, vehicle in running order, engine under full load.
Preparation
Remove the engine cover.
IMPERATIVE : Do not disconnect the air temperature sensor (3).
If the warning lamp in the instrument panel should come on, delete the faults using the
diagnostic tool.
Remove the clips (1).
Move aside the duct (2) without disconnecting the air temperature sensor (3).
Fit the tool [2] in the place of the duct (2).
Couple the pressure gauge [2] on the sleeve [1] using the tube «a».
C5F2002D
B1B2007D
