49
ENGINE
B1B2011D
AUXILIARY EQUIPMENT DRIVE BELT
Engine : 8HT
Compress the dynamic tensioner roller, using tool [1].
Position the peg [2].
Remove the auxiliary drive belt (7).
Refitting
NOTE : Check that the tensioner roller moves freely (no tight spot). If this is not
the case, replace the tensioner roller.
Respect the direction of fitting of the drive belt.
Position the auxiliary drive belt.
Move the tool [2] on the tensioner roller to remove the peg [3].
Make sure that the drive belt is correctly positioned in the «V» grooves of the
various pulleys.
Refit the splash-shield.
Reconnect the battery negative cable.
IMPERATIVE : Carry out the operations that are necessary following a
reconnection of the battery
(see corresponding operation)
.
