[SM-P00081-A]
−8−
1
PRODUCT
2) Slave unit specifications
The product must be used within the following specifications.
Descriptions
Specifications
Model
N4E0-T7EC1 N4E0-T7EC2 N4E0-T7ECT1 N4E0-T7ECT2
Wiring output port port side wiring side
Unit power voltage 21.6VDC to 26.4VDC (24VDC±10%)
Unit power current consumption 120mA or less (at 24.0VDC with all points ON)
Valve power voltage 22.8VDC to 26.4VDC (24VDC+10%, -5%)
Valve power current consumption 15mA or less (all points OFF)
Output type
NPN output ( +COM )
Number of output points 16 points 32 points 16 points 32 points
Node address setting
With switch 01~FF (Hex) [1 to 255 (Dec)]
With master 01〜FFFF (Hex) [1 to 65535 (Dec)]
Output setting when
communication error occurs
Hold (all outputs are maintained) / Clear (all outputs are turned off)
Insulation resistance Between external terminals and case: 30 MΩ or more with 500 VDC
Withstand voltage
Between external terminals and case: 500 VAC for 1 minute
Shock resistance 294.0m/s
2
for 3 times in 3 directions
Storage ambient temperature
-20 to 70°C
Storage humidity
30 to 85%RH (no dew condensation)
Ambient temperature -5 to 55°C
Ambient humidity 30 to 85%RH (no dew condensation)
Atmosphere No corrosive gas
Communication protocol
EtherCAT (asynchronous
Note2
)
Baud rate Full-duplex 100Mbps
Output insulation Photo coupler insulation
Maximum load current 40 mA/1 point
Leakage current 0.1mA or less
Residual voltage 0.5V or less
Fuse
Valve power: 24 V, 3 A / Unit power: 24 V, 1 A
(both fuses are non-replaceable)
Operation indicator
LED(communication status, unit and valve power supply status
Note3
)
Degree of protection
IP40
Vibration
resistance
Durability
10Hz to 150Hz to 10Hz, 1 octave/min., 15 sweeps each in X, Y, Z
directions with 0.75mm half-amplitude or 98.0m/s
2
, whichever smaller
Malfunction
10Hz to 150Hz to 10Hz, 1 octave/min., 4 sweeps each in X, Y, Z directions
with 0.5mm half-amplitude or 68.6m/s
2
, whichever smaller
Note1. Slave units follow address restriction from the master unit.
The factory setting of the rotary switch is "00". To set the node address from the master unit, set the
rotary switch to "00".
Note2. Synchronization with other slave units is not supported. It is not recommended to use the product in an
environment that requires precise time management (This slave unit does not support DC mode and SM
mode).
Note3. Monitoring is available when the voltage within the specified range is supplied to the unit power.
To Next Page
