PROXIMA STX
Ice-Cream Cabinet
ENGLISH
16
Respect national regulations for electrical installations.
Position the master switch in the OFF position.
The display cabinet is supplied with a 5-wire cable;
• Yellow/Green = Grounding wire
• Blue = Neutral Line
• Brown = phase 1
• Grey = Phase 2
• Black = Phase 3
WARNING:
Never cut or remove the yellow-green cable mentioned above.
The five power supply wires must be connected to the back-bone network, which a san
efficient earth system, in compliance with national and local regulations (where present)
regarding electrical installations and suitable for the electric absorption of the display cabinet,
refer to chapter 2 – Total Absorbed Power.
WARNING:
The electrical connection to the mains must be made using the five
Moreover, the central plant to which the display cabinet is connected must have a
switch with contact opening of at least 3 mm protected by fuses.
WARNING:
Apply a suitable method of fixing to the power supply cable on the connection box,
making reference to the table shown below.
Rated Current
[A]
Rated Section [mm
2
]
Gen. Purpose Flex
Cables [mm
2
]
Grounding Cables [mm
2
]
3 0,5
÷
0,75 1
÷
2,5
3 ÷ 6 0,75
÷
1 1
÷
2,5
6 ÷ 10 1
÷
1,5 1
÷
2,5
10 ÷ 16 1,5
÷
2,5 1,5
÷
4
16 ÷ 25 2,5
÷
4 2,5
÷
6
25 ÷ 32 4
÷
6 4
÷
10
32 ÷ 40 6
÷
10 6
÷
16
40 ÷ 63 10
÷
16 10
÷
25
3.7
WATER DRAIN PIPE
If the cabinet is supplied with external drains for condensation / defrosting or periodic
cleaning water discharge, be sure to connect the drain pipes to the sewer.
