Clarion M505 Owner's Manual & Installation Manual

English
Owner’s Manual
M205/M505
22
5. WIRE CONNECTION
Wired Remote
(M505 only)
Black
Black
OEM Steering Wheel
16-Pin Connector
Extension Lead
Yellow wire
(Memory back-up lead)
Connect directly
to battery
Red wire
(Power lead)
Accessory
12V
Blue wire
Purple/Black
Green
Green/Black
Grey
Front Right
Antennal
White
White
White
White
Front
Channel
Rear
Channel
2-Zone
Subwoofer
Grey
Black
Green
Purple
Black
Left
Left
Left
Right
Right
Right
Red
Red
Red
Red
Front Left
Rear Right
Rear Left
Grey/Black
White
White/Black
Purple
Power Antenna
Blue/White wire
(Amplierturn-onlead)
Orange/White wire
(Illumination lead)
Connect to the vessel power
supply terminal for illumination
Black wire (Ground lead)
Connect to vessel chassis ground
•
Connect to remote turn-on lead
ofamplier
•
Connect it to the vessel power
supply terminal for antenna
Black
SiriusXM
(M505 only)
