NX503E English 61
3.1.10 Building a route from the list of destinations (Create Route)
You can also build your route destination by destination from the My Route menu.
1. If you are on the Map screen, tap
to return to the Navigation Menu.
2. In the Navigation Menu, tap
.
3. Tap
.
4. There is only one line in the list of route points, the start point of the route, normally the
current GPS position.
5. Tap
to select the destination.
6. The Destination menu appears and you can select the destination of the route the
same way as described in the previous sections.
7. When the new destination is selected, the list returns.
8. To add more destinations, tap
where you want to insert the new route point in
the list, and repeat the above procedure.
