Clevo N150RD Service Manual

Disassembly
2 - 16 Removing the 3G/4G Module
2.Disassembly
Removing the 3G/4G Module
3G/4G Module Removal Procedure
1. Turn off the computer, remove the battery (page 2 - 5), and bottom case (page 2 - 6).
2. Locate the module, it is visible at point
(Figure 11a).
3. Carefully disconnect the cables & , and then remove the screw from the module
(Figure 11b).
4. The module will pop-up
(Figure 11c).
5. Lift the module up and off the computer
(Figure 11d).
1
2
3
4
3
5
a.
b.
1
2
5
c.
3
4
5
d.

5. 3G/4G Module
•1 Screw
Figure 11
3G/4G Module
Removal
a. Locate the module.
b. Disconnect the cables and
remove the screw.
c. The module will pop-up.
d. Lift the module up off the
socket.
