IS-NT-Async-SPI, SW Version 1.2, ©ComAp – February 2011
IS-NT-Async-SPI-1.2.PDF
19
Multi language support
NT Family controllers support up to five Languages that is possible to switch during controller duty. Every
terminal (i.e. Remote display or PC-InteliMonitor) can be switched to different language. Use PC-GenConfig
- Translator tool to translate texts to another language.
Default application archives contain all texts in English only.
ECU interface customizing
The list of available ECU interfaces can be found in GenConfig / Modules / ECU list.
Binary selector
This function enables to change the following CAN values transmitted to ECU via J1939 or binary output
only. The change can be provided by setpoint or via Binary input. There are four Bin selector channels
available.
J1939 value ECU command
Governor mode Isochronous - Droop
Idle Speed select Idle – Nominal
Frequency select 1500 – 1800
Preheat request Yes – No
Protection override Yes – No
