Page #7 background imageLoading...
Page #7 background image
IS-NT-Async-SPI, SW Version 1.2, ©ComAp – February 2011
IS-NT-Async-SPI-1.2.PDF
7
AUT mode
No AMF function in SPI application.
Remote start/stop
Gen-set starts automatically, when binary input REM START/STOP is closed and stops when the input is
opened. If there is no mains present or the MCB feedback is not closed, the gen-set won’t start.
When Mains is within limits and MCB feedback is closed the controller starts RPM matching and
closes GCB when all matching conditions are met (see in MAN mode). Gen-set remains running in
parallel.
When Mains failure is recognized during parallel operation - controller opens GCB and if this state
continues for 1 minute, it will stop the engine.
After mains recovers and MCB feedback is closed again (MCB is controlled externally), the controller
starts RPM matching and closes GCB when all matching conditions are met. Gen-set remains
running in parallel.
Peak shaving
Gen-set can start and stop automatically according to consumption from the mains (object). IE measurement
must not be set to NONE and ProcessControl:PeakAutS/S del must be greater than 0.
If Mains import value exceeds for more than ProcessControl:PeakAutS/S del
ProcessControl:PeakLevelStart, engine starts automatically.
If Load consumption (Mains import + Gen-set power) drops for more than ProcessControl:PeakAutS/S del
below ProcessControl:PeakLevelStop, engine stops.
Hint:
Engine does not stop, if some other condition for automatic start is active.
Example: If peak stop condition occurs, but REMOTE START/STOP is active, engine stays running.
The controller does not respond to GCB ON/OFF, STOP, START buttons and corresponding remote
commands of InteliMonitor or Modbus communication.
Set Basic setting: FltRes GoToMAN = ENABLED to avoid automatic engine start when pressing FAULT
RESET after any 2
nd
level alarm (Shutdown, Slow stop, Breaker Open&Cooldown).
Active Power control modes in SPI
Mode Function Setpoints
Baseload Gen-set power is constant - set by
Baseload setpoint.
ProcessControl: Load ctrl PtM=BASELOAD;
Base load
ANEXT Baseload Gen-set power is set via Analog input. ProcessControl: Load ctrl ANEXT Baseload;
Analog input: LdCtrlAnextBld
Import / Export Import/Export value is constant – I/E
power is measured by controller.
ProcessControl: Load ctrl PtM=IM/EX;
Import load; I/E Pm-meas = IM3 CT INPUT
ANEXT
Import / Export
Import/Export value is constant – I/E
power is measured via Analog input.
ProcessControl: Load ctrl PtM=IM/EX;
Import load; I/E Pm-meas = ANALOG INPUT
Analog input: LdCtrl:I/E-Pm
Warming The controller limits gen-set power for
requested time or until the water
temperature reach the requested value.
After warming the gen-set goes to the
requested (e.g. Baseload) power.
Engine params: Warming load;
Warming temp; Max warm time
Peak shaving Automatic gen-set start/stop based on
object (load) consumption.
ProcessControl: PeakLevelStart;
PeakLevelStop; PeakAutS/S del
Export limit Limits export to the mains in the
Baseload mode.
ProcessControl: Export limit = ENABLE
