IS-NT-Async-SPI, SW Version 1.2, ©ComAp – February 2011
IS-NT-Async-SPI-1.2.PDF
34
LdShed stage 1
LdShed stage 2
LdShed stage 3
Load shedding outputs for partial load switching.
Derating 1 act
Indicates activity of derating function 1.
Derating 2 act
Indicates activity of derating function 2.
Binary outputs – Control loops
Speed up
Speed dn
Binary outputs for Synchronizing and Load control. Outputs can be used instead of analog Speed governor
output for older engine types. Minimum pulse duration is 0,15 sec. Maximum pulse duration is 10,0 sec.
Hint:
When Speed governor output stays near to the limit value (SpeedGovLowLim+0,2 V or SpeedGovHiLim-0,2
V) for more than 2 sec, the “Wrn SpdRegLim” message is displayed in the Alarm list and recorded to History.
When AVRi output stays on <2% or >98% for more than 2 sec, the “Wrn VoltRegLim” is displayed in the
Alarm list and recorded to History.
Corresponding warning is blocked when Binary outputs Speed Up, Speed Dn or AVR up, AVR dn are
configured to a physical BO or VPIO.
It is not recommended to process these signals via the internal PLC, as the precise signal timing would be
distorted.
RemoteControl1
RemoteControl2
RemoteControl3
RemoteControl4
RemoteControl5
RemoteControl6
RemoteControl7
RemoteControl8
These outputs are controlled remotely from InteliMonitor or other tool. The user selects the requested state
of these outputs via the buttons in this program.
Hint:
Outputs can be used to switch on/off some auxiliary devices in the control panel.
