KNOW YOUR PRESSURE WASHER
Read the Operator’s Manual and safety rules before operating your pressure washer.
Compare the illustrations with your pressure washer to familiarize yourself with the locations of various
controls and adjustments. Save this manual for future reference.
FEATURES AND CONTROLS
A - Fold Down Handle
for space-saving storage.
B - Accessory Tray — Provides convenient storage for
accessories, such as gun, nozzle extension, etc.
C - Recoil Starter — Used for starting the engine manually.
D - Oil Fill/Dipstick — Check, add and drain engine oil here.
E - Identication Label — Provides model and serial
F - Engine Identication — Provides model and type of
assistance.
G - Automatic Cool Down System — Cycles water through
discharge from pump onto ground. This system prevents
internal pump damage.
H - Pump — Develops high pressure.
J - High Pressure Outlet — Connection for high pressure
hose.
K - Water Inlet — Connection for garden hose.
L - Selector Nozzle
nozzles for various applications.
M - Nozzle Extension with Quick Connect — Allows you
accessories.
N - Air Filter
out of intake air.
P - Engine Rocker Switch — Push this switch to ON (I)
R - Warning/Operating Instructions Tag
hazards and proper procedure to start/stop pressure
washer.
S - Fuel Tank — Fill tank with regular unleaded fuel. Always
leave room for fuel expansion.
T - Project Pro® PerfectMix™ Siphon — Mixes
concentrate with pressure washer spray.
U - High Pressure Hose — Connect one end to water pump
and the other end to spray gun.
V - Spray Gun — Controls the application of water onto
cleaning surface with trigger device. Includes trigger lock.
