Crestron DM-TX-201-C User Manual

DigitalMedia 8G+™ Transmitter 201 Crestron DM-TX-201-C
DM-TX-201-C Specifications (Continued)
SPECIFICATION DETAILS
Video
Input Resolutions (Continued)
HDMI & DVI Interlaced
720 x 480 @ 30 Hz (480i)
720 x 576 @ 25 Hz (576i)
1920 x 1080 @ 25 Hz (1080i25)
1920 x 1080 @ 30 Hz (1080i30)
plus any other resolution allowed by HDMI
up to 165 MHz pixel clock
RGB
640 x 480 @ 60 Hz
720 x 480 @ 60 Hz (480p)
720 x 576 @ 50 Hz (576p)
800 x 600 @ 60 Hz
848 x 480 @ 60 Hz
1024 x 768 @ 60 Hz
1280 x 720 @ 50 Hz (720p50)
1280 x 720 @ 60 Hz (720p60)
1280 x 768 @ 60 Hz
1280 x 800 @ 60 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 Hz
1360 x 768 @ 60 Hz
1366 x 768 @ 60 Hz
1400 x 1050 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 1200 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 50 Hz (1080p50)
1920 x 1080 @ 60 Hz (1080p60)
1920 x 1200 @ 60 Hz
2048 x 1152 @ 60 Hz
Component
2
480i, 576i, 480p, 576p, 720p50, 720p60,
1080p24, 1080i25 (1125 lines), 1080i30,
1080p30, 1080p50 (1125 lines), 1080p60
Composite and S-Video
2
480i, 576i
Output Resolutions Matched to inputs
Analog to Digital Conversion 10-bit 165 MHz per each of three channels
Audio
Switcher 2x1 combination digital/analog switch
Input Signal Types
HDMI, DisplayPort Multimode
1
, analog
stereo
Output Signal Types DM 8G+, HDMI
Formats, HDMI
Dolby Digital
®
, Dolby Digital EX, DTS
®
,
DTS-ES, DTS 96/24, up to 8ch PCM
Formats, Analog Stereo 2-channel
Analog to Digital Conversion 24-bit 48 kHz
(Continued on following page)
6 • DigitalMedia 8G+™ Transmitter 201: DM-TX-201-C Operations & Installation Guide – DOC. 6958B

Crestron DM-TX-201-C Specifications

General

Type	Network transmitter
Duplex system	Full, Half
Auto-negotiation	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3at
RJ-45 ports quantity (transmitter)	2
Product color	Black
Output current	0.75 A
Output voltage	24 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32 mm
Width	187 mm
Height	165 mm
Weight	721 g
