Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194446-25450 BALL BEARING 1
2 CY-198241-28100 GEAR KIT,DRIVE 1
3 CY-198133-28110 SHAFT, FRONT DRIVE 1
4 CY-194765-28170 GEAR,FRONT DRIVE 1
5 CY-198254282701 SLIDER 1
6 CY-198241-28220 GEAR, FRONT DRIVE 1
7 CY-194321-28230 SPRING 26.2 1
8 CY-198241-28240 COLLAR 1
9 CY-24101-060074 BALL BEARING #6007 1
10 CY-24190-080001 BALL 1/4, STEEL 2
11 CY-24421-356212 SEAL TC35 62 12, OIL 1
102
FIG. 52. FRONT DRIVE
Copyright 2008 Cub Cadet Yanmar LLC
