Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198240-12650 BOLT M14X 28 4
2 CY-198133751101 HITCH, DRAWBAR 1
3 CY-198133751301 BRACKET, DRAWBAR 1
4 CY-198133-75320 PIN 1
5 CY-22351-060040 SPRING PIN 6X40 1
6 CY-198240-75440 PIN 12X 70 2
7 CY-22137-120000 WASHER 12,POLISHED 2
8 CY-22217-120000 SPRING WASHER 12 2
9 CY-22360-190000 SNAP PIN 19 1
10 CY-22372-120000 SNAP PIN 12 2
11 CY-26013-120302 BOLT W/WASHER M12X30 4
12 CY-26716-120002 NUT 12 2
173
FIG. 100. DRAW BAR HITCH
Copyright 2008 Cub Cadet Yanmar LLC
