Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198320-36200 BRAKE ASSY, 1
2 CY-198240-36310 ACTUATOR L 1
3 CY-198240-36320 ACTUATOR R 1
4 CY-198240-36351 PLATE 226, FRICTION 6
5 CY-198240-36520 PLATE 3.2, STEEL 5
6 CY-194205-36320 SPRING, ACTUATOR 4
7 CY-198240-36380 HOOK, RETURN SPRING 4
8 CY-198240-36700 LEVER COMPL.,CAM 1
9 CY-198240-36710 CAMSHAFT, BRAKE 1
10 CY-198240-36720 CAMSHAFT, BRAKE 1
11 CY-198240367301 SHAFT, CAM LEVER 2
12 CY-198320-36790 SLEEVE, CAM LEVER 2
13 CY-22242-000290 CIRCLIP 29 2
14 CY-24190-180001 BALL 9/16 12
15 CY-24421-304208 SEAL TC30 42 08, OIL 2
113
FIG. 62. BRAKE
Copyright 2008 Cub Cadet Yanmar LLC
