Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194180-12471 NUT,CASTLE 2
2 CY-798254-17500 CYLINDER ASSY, 1
3 CY-198254-17510 CYLINDER ASSY, 1
4 CY-1A7335-17310 CAP, CYLINDER 1
5 CY-1A7335-17410 ROD ASSY 1
6 CY-1A7335-17500 LOCK NUT 1
7 CY-1A7335-17520 CIRCLIP 120 1
8 CY-1A7335-17530 CIRCLIP 120 1
9 CY-1A7335-17550 SEAL KIT 1
10 CY-1A7335-17750 PISTION 1
11 CY-194065-38380 ADPTER 1/4 2
12 CY-22417-400250 COTTER PIN 4.0X25 2
69
FIG. 27. PST CYLINDER
Copyright 2008 Cub Cadet Yanmar LLC
