Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-129795-01960 PIPE, KNOCK 2
2 CY-129457-28000 BALANCER ASSY 1
3 CY-128170-14150 NUT, CAM 1
4 CY-121850-21290 PIN 1
5 CY-129457-28011 CASE ASSY, BALANCER 1
8 CY-729490-28510 SHAFT, BALANCER A 1
13 CY-729490-28520 SHAFT, BALANCER B 1
18 CY-129400-28150 GEAR, BALANCER A 1
19 CY-23876-005000 PLUG, PT1/16 1
20 CY-26106-080142 BOLT 8X 14 PLATED 4
21 CY-24311-000140 O-RING 1A P-14.0 1
22 CY-26106-080602 BOLT M 8X 60 PLATED 4
23 CY-26106-080802 BOLT M 8X 80 PLATED 2
24 CY-129400-28920 BUSH 4
19
FIG. 10. BALANCER
Copyright 2008 Cub Cadet Yanmar LLC
