Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198255341101 SHAFT,REAR AXLE 2
2 CY-194640-34130 WASHER 13X64X9 2
3 CY-194640-34140 BOLT M12X30 2
4 CY-194640-34150 WASHER, THRUST 2
5 CY-194145-34360 SEAL COLLAR 60X75X26 2
6 CY-194145-34390 SPACER 2
7 CY-24101-060114 BALL BEARING 2
8 CY-24101-062124 BALL BEARING 2
9 CY-24321-000600 O-RING 1A G-60.0 2
109
FIG. 58. REAR AXLE SHAFT
Copyright 2008 Cub Cadet Yanmar LLC
