Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-24761-010000 NIPPLE M6F, GREASE 1
2 CY-198241-28330 GUIDE,FRONT SHIFT 1
3 CY-198240374202 PEDAL L.H., BRAKE 1
4 CY-198240374702 PEDAL R.H., BRAKE 1
5 CY-198240-37510 SPRING, RETURN 2
6 CY-198240375501 SHAFT, BRAKE PEDAL 1
7 CY-198253-37610 KNOB, PARKING 1
8 CY-1A7780-37620 ROD,PARKING CMP 1
9 CY-198254-37660 LEVER,PARKING BRAKE 1
10 CY-198220-37700 SPRING 1
11 CY-198220-37720 SPRING 1
12 CY-794525-37000 ROD KIT,BRAKE 1
13 CY-194150-22480 NUT M10 2
14 CY-194130-37730 TURNBUCKLE M10X70 2
15 CY-194310-37741 ROD, BRAKE 2
16 CY-194134-37771 ROD, BRAKE 2
17 CY-26716-100002 NUT 10 2
18 CY-198240-37850 LEVER(B, PARKING 1
19 CY-198220-37900 PIN 8X24 4
20 CY-22272-000190 CIRCLIP E-19 1
21 CY-22417-200300 COTTER PIN 2.0X30 1
22 CY-22417-250300 COTTER PIN 2.5X30 4
23 CY-22417-250300 COTTER PIN 2.5X30 1
24 CY-22487-100700 PIN 10X 70 1
25 CY-22512-070400 KEY 7X 40 1
115
FIG.63. BRAKE PEDAL
Copyright 2008 Cub Cadet Yanmar LLC
