Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-26106-080122 BOLT M 8X 12 PLATED 1
2 CY-194990-22140 NUT W/WASHER 8 1
3 CY-194990-22140 NUT W/WASHER 8 2
4 CY-1E8080-43850 CLAMP,CHAFF WIRE 2
5 CY-1A8170-51100 WIRING HARNESS A CMP 1
6 CY-1A7500-51130 DIODE, 3.0A 2
7 CY-1A8160-51130 DIODE, 3.0AX2 3
8 CY-194275-51160 COUPLER 1
9 CY-194275-51170 PLUG 1
10 CY-1A7500-51170 CLIP, HARNESS 6
11 CY-198535-52110 FUSE 5
12 CY-198535-52120 FUSE 10A 4
13 CY-198535-52130 FUSE 15A 2
14 CY-1A7531-52420 COVER, FUSE BOX 1
15 CY-1A8170-65440 LABEL,FUSE 1
16 CY-198153-51700 BLOW 79A,SLOW CMP 2
17 CY-194170-51210 GROMMET 25 2
18 CY-194275-51210 GROMMET 25 1
19 CY-194275-51210 GROMMET 25 2
20 CY-1A8160-51310 WIRING HARNESS, 1
21 CY-198153-51420 CABLE,BATTERY EARTH 1
22 CY-198071-51411 CABLE, BATTERY 1
23 CY-198121-51430 CLAMP, B.CABLE 1
24 CY-194440-51620 CLAMP, WIRE HARNESS 2
25 CY-194440-51620 CLAMP, WIRE HARNESS 1
26 CY-194440-51620 CLAMP, WIRE HARNESS 2
27 CY-194440-51620 CLAMP, WIRE HARNESS 2
28 CY-194440-51620 CLAMP, WIRE HARNESS 1
29 CY-194440-51620 CLAMP, WIRE HARNESS 1
30 CY-194440-51620 CLAMP, WIRE HARNESS 1
31 CY-194250-51650 CLAMP 66 4
32 CY-1A7260-51710 GROMMET, CABLE 1
33 CY-1A7000-61490 TRIM, 120 1
34 CY-1A7000-61490 TRIM, 120 1
35 CY-198291-77870 COVER,HOSE PROTECTOR 1
36 CY-26106-060162 BOLT M 6X 16 PLATED 2
37 CY-26106-080122 BOLT M 8X 12 PLATED 1
38 CY-26106-080122 BOLT M 8X 12 PLATED 1
39 CY-26106-080162 BOLT M 8X 16 PLATED 2
40 CY-26106-080162 BOLT M 8X 16 PLATED 1
41 CY-26106-080252 BOLT M 8X 25 PLATED 2
42 CY-26106-080352 BOLT M 8X 35 PLATED 1
43 CY-29622-140001 BAND 140 1
44 CY-29622-140001 BAND 140 1
45 CY-29622-140001 BAND 140 4
46 CY-29622-140001 BAND 140 2
47 CY-29622-140001 BAND 140 2
48 CY-29622-140001 BAND 140 1
49 CY-29622-250001 BAND RF 250 1
50 CY-194180-51640 CLAMP, WIRE HARNESS 1
51 CY-26013-100162 BOLT M10X 16 1
52 CY-1A8170-51130 WIRING HARNESS C CMP 2
137
FIG. 77. WIRE HARNESS
Copyright 2008 Cub Cadet Yanmar LLC
