Ex Series Ex450

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194990-22140 NUT W/WASHER 8 3

2 CY-1A7780-60340 FRAME ASSY,SIDE L.H. 1

3 CY-1A8170-60350 FRAME ASSY,SIDE R.H. 1

4 CY-1A7780-60370 PLATE ASSY,UPPER 1

5 CY-1A7780-60480 SUPPORT, L.H. COVER 1

6 CY-1A7780-60490 SUPPORT, R.H. COVER 1

7 CY-1A7260-60911 HINGE ASSY,HOOD 1

8 CY-1A7260-60580 SPRING, L.H. 1

9 CY-1A7260-60590 SPRING, R.H. 1

10 CY-1A7260-61080 PLATE, LOWER 1

11 CY-1A7260-61190 PIN, 1

12 CY-22272-000080 CIRCLIP E- 8 2

13 CY-1A7260-60920 BRACKET, L.H. COVER 1

14 CY-1A7260-60930 BRACKET, R.H. COVER 1

15 CY-1A7890-60980 CUSHION 1

16 CY-1A7780-61672 PLATE ASSY,SHIELD 1

17 CY-198153-89730 STRIP,DUCT WEATHER 1

18 CY-26106-060122 BOLT M 6X 12 PLATED 4

19 CY-26106-080122 BOLT M 8X 12 PLATED 4

20 CY-26106-080162 BOLT M 8X 16 PLATED 6

21 CY-26106-080162 BOLT M 8X 16 PLATED 2

22 CY-26106-080162 BOLT M 8X 16 PLATED 3

23 CY-26106-080162 BOLT M 8X 16 PLATED 4

24 CY-26106-080162 BOLT M 8X 16 PLATED 4

149

FIG. 86. FRAME, HOOD

Cub Cadet Ex450 User Manual
