Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198230-17301 COLUMN, STEERING 1
2 CY-198230-17311 COLUMN ASSY 1
3 CY-194640-17340 BUSH, COLUMN 1
4 CY-198230-17340 SHAFT ASSY 1
5 CY-22242-000200 CIRCLIP 20 1
6 CY-22252-000420 CIRCLIP 42 1
7 CY-24104-060040 BALL BEARING 1
8 CY-198251-17500 VALVE ASSY, STEERINJ 1
9 CY-194337-17220 CAP 1
10 CY-194337-17251 PLATE, SPACER 1
11 CY-194337-17390 RING 1
12 CY-194337-17400 BUSH 1
13 CY-198220-17610 SCREW 6
14 CY-198220-17620 SCREW 1
15 CY-198153-17630 BEARING COMP.,NEEDLE 1
16 Order Ref No. 15 BEARING 2
17 CY-194337-17350 THRUST NEEDLE 1
18 CY-198220-17642 KIT,SEAL 1
19 CY-194337-17330 O-RING 2
20 CY-194337-17360 O-RING 1
21 CY-194337-17370 SEAL, OIL 1
22 CY-194337-17380 SEAL, DUST 1
23 Order Ref No. 18 SEAL 1
24 CY-198220-17680 O-RING 1
25 CY-198220-17651 VALVE ASSY, CONTROL 1
26 CY-198220-17660 DRIVE COMP.,DIROTOR 1
27 CY-198220-17631 GEROTOR 1
28 CY-198390-17660 SEAL 1
29 CY-198220-17670 DRIVE 1
30 CY-24190-070001 BALL 7/32 1
31 CY-198240-17870 COVER, CLUTCH 1
32 CY-198327-21150 PACKING,CLUTCH C 1
33 CY-26013-120202 BOLT W/WASHER M12X20 4
34 CY-26106-080162 BOLT M 8X 16 PLATED 2
35 CY-26106-100252 BOLT M10X 25 PLATED 4
36 CY-26106-100252 BOLT M10X 25 PLATED 4
71
FIG.28. PST VALVE
Copyright 2008 Cub Cadet Yanmar LLC
