Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198149241011 HOUSING,TRANSMISSION 1
2 CY-198240-24120 STUD 16*45 4
3 CY-198240-24530 STUD 12*45 2
4 CY-22312-100180 PARALLEL PIN 10X 18 2
5 CY-26218-080202 STUD M 8X 20 2
6 CY-26218-100902 STUD M10X 90 PLATED 2
7 CY-198240-24140 PACKING, MISSION 1
8 CY-198327242401 COVER, REAR 1
9 CY-198240-24320 PACKING 1
10 CY-198133243701 COVER, FRONT DRIVE 1
11 CY-198133-24380 COUPLING 140=3 1
12 CY-198138-24390 PACKING 1
13 CY-198255244601 PLATE, OIL SEAL 1
14 CY-198240244801 COVER 1
15 CY-198240245101 COVER 1
16 CY-198240246821 COVER,MISSION 1
17 CY-198240-24690 CAP ASSY 1
18 CY-198240249201 FLANGE 1
19 CY-194215-24960 PIPE 1
20 CY-194850-24960 GAUGE COMP,OIL 1
21 CY-119860-34810 GUIDE, DIPSTICK 1
22 CY-194850-42500 CAP, OIL 33 1
23 CY-198220459201 PLUG 3/4-16UNF 1
24 CY-194640-73180 PIN, LOWER LINK 2
25 CY-22217-100000 SPRING WASHER 10 2
26 CY-22217-160000 SPRING WASHER 16 4
27 CY-22312-100180 PARALLEL PIN 10X 18 2
28 CY-23414-190000 PACKING -19 1
29 CY-23491-140002 PLUG 14 2
30 CY-24311-000160 O-RING 1A P-16.0 2
31 CY-24311-000500 O-RING 1A P-50.0 1
32 CY-24321-000300 O-RING G30 1
33 CY-24321-000300 O-RING G30 2
34 CY-24321-000750 O-RING 1A G-75.0 1
35 CY-26013-080162 BOLT W/WASHER M8X16 8
36 CY-26013-080162 BOLT W/WASHER M8X16 2
37 CY-26013-080202 BOLT W/WASHER M8X20 2
38 CY-26013-080202 BOLT W/WASHER M8X20 2
39 CY-26013-080252 BOLT M 8X 25 5
40 CY-26013-080302 BOLT M 8X 30 4
41 CY-26013-080352 BOLT M 8X 35 10
42 CY-26013-080502 BOLT M 8X 50 2
43 CY-26013-100252 BOLT W/WASHER M10X25 4
44 CY-26013-120402 BOLT M12X 40 2
45 CY-26013-140352 BOLT W/WASHER M14X35 4
46 CY-26716-100002 NUT 10 2
47 CY-26716-160002 NUT M16 4
81
FIG. 35. TRANSMISSION CASE
Copyright 2008 Cub Cadet Yanmar LLC
