D-Link DAP-2682 User Manual

77D-Link DAP-2682 User Manual
Section 3 - Conguration
System Name Settings
Each of the eight main categories display various hidden administrator parameters and settings.
System Name:
Location:
The name of the device. The default
name is D-Link DAP-2682.
The physical location of the device, e.g.
72nd Floor, D-Link HQ.
Login Settings
Each of the eight main categories display various hidden administrator parameters and settings.
Login Name:
New Password:
Conrm Password:
Enter a user name. The default is admin.
When changing your password, enter the
new password here. The password is
case-sensitive. “A” is a dierent character
than “a.” The length should be between 0 and 12 characters.
Enter the new password a second time for conrmation purposes.
Console Settings
Each of the eight main categories display various hidden administrator parameters and settings.
Status:
Console Protocol:
Time-out:
Status is enabled by default. Uncheck the
box to disable the console.
Select the type of protocol you would
like to use, Telnet or SSH.
Set to 1 Min, 3 Mins, 5 Mins, 10 Mins, 15 Mins or Never.

D-Link DAP-2682 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
Virtual LAN features	Multiple VXLAN (MUX VLAN)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mean time between failures (MTBF)	341897 h
Maximum data transfer rate (5 GHz)	1700 Mbit/s
Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	SSID broadcast
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	2
Input current	2.5 A
AC input voltage	12 V
Power consumption (max)	15.5 W
Placement	Ceiling, Wall
Certification	FCC, CE, UL
Product color	White
LED indicators	Power, Status
Antenna type	Internal
Antenna gain level (max)	4.8 dBi
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	190 mm
Height	43.7 mm
Weight	551.6 g
