D-Link DAP-2682 User Manual

9D-Link DAP-2682 User Manual
Setup Wizard
The rst login instance displays the System Settings window which requires a change in password. Additional settings include the System Time
and System Country functions.
After logging in to the user interface, ll in the New Password and Conrm New Password elds.
In the System Time function, select Using Network Time Protocol (NTP) or Manually to dene the system time. If required, click the Daylight
Saving Oset drop-down menu and select the value (minutes).
y Setting NTP System Time: Before trying to congure NTP check, perform a ping test with the NTP server. In the NTP Server eld, enter the NTP
server to use. Then click the Time Zone drop-down menu and select the appropriate time zone.
y Setting System Time Manually: From the System Date drop-down menu, select the Year, Month, and Day along with the Hour and Minutes
appropriate for the AP.
y Enable Daylight Saving: Click the radio button to enable the daylight savings time (DST) function. Set the DST start (24 hours) and end (24
hours) time by clicking on the drop-down menus and setting the Month, Week, Day, Hour, and Minute of the DST starting days.
Once the settings are congured, click Update button to accept the conguration and proceed to the main interface menu page.

D-Link DAP-2682 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
Virtual LAN features	Multiple VXLAN (MUX VLAN)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mean time between failures (MTBF)	341897 h
Maximum data transfer rate (5 GHz)	1700 Mbit/s
Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	SSID broadcast
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	2
Input current	2.5 A
AC input voltage	12 V
Power consumption (max)	15.5 W
Placement	Ceiling, Wall
Certification	FCC, CE, UL
Product color	White
LED indicators	Power, Status
Antenna type	Internal
Antenna gain level (max)	4.8 dBi
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	190 mm
Height	43.7 mm
Weight	551.6 g
