D-Link DES-1008D User Manual

10/100 Dual-Speed Switch User’s Guide
20
Connecting The Switch
blocks do not meet this standard, an upgrade is
necessary.
We recommend using Category 5 cabling for all connections in
order to make it easier to transition all stations to 100 Mbps.
Different connection schemes require different types of cable.
Please use the following chart when choosing cables:
DEVICE
PORT
USED
DEVICE BEING
CONNECTED
PORT
TYPE
CABLE TO USE
Hub or
Normal Crossover (X)
Normal
Switch
Uplink Straight-Through (||)
Switch
Server (or PC) Straight-Through (||)
Hub or
Normal Straight-Through (||)
Uplink
Switch
Uplink Crossover (X)
Server (or PC) Crossover (X)
A crossover cable is a normal straight-through twisted-pair cable in
which the wires have been crossed at one end. Please refer to
Appendix B: Cables and Connectors for more detailed information
about crossover cables.
PC to Switch
A PC can be directly connected to the switch, giving the PC a high-
bandwidth dedicated connection to the network. The PC must first
be fitted with a 10BASE-T Ethernet, 100 BASE-TX Fast Ethernet
or 10/100 dual-speed network interface card (NIC) with an RJ-45
jack for twisted-pair connections. In the case of 10BASE-T, the PC
can be connected using a Category 3, 4 or 5 UTP/STP straight
cable; a 10/100 dual-speed or 100BASE-TX connection needs

D-Link DES-1008D Specifications

General

Switch type	Unmanaged
Switch layer	-
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Full duplex	Yes
Networking standards	IEEE 802.3, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
MAC address table	1024 entries
Product color	Black
Maximum data transfer rate	100 Mbit/s
Mean time between failures (MTBF)	116186 h
Input current	1 A
Output voltage	5 V
Package depth	158 mm
Package width	104 mm
Package height	94 mm
Package weight	310 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1885 mm
Pallet gross weight (air)	330500 g
Quantity per pallet (air)	1000 pc(s)
Shipping (inner) case width	211 mm
Shipping (inner) case height	350 mm
Shipping (inner) case length	543 mm
Shipping (inner) case weight	6230 g
Shipping (inner) case net weight	3960 g
Number of cartons per pallet (air)	50 pc(s)
Quantity per shipping (inner) case	20 pc(s)
Harmonized System (HS) code	85176990
