10/100 Fast Ethernet Switch User’s Guide
10
Unpacking and Setup
Then, use the screws provided with the equipment rack to mount the Switch
in the rack.
Figure 2.3 Installing the Switch in an equipment rack
Power on
The Switch can be used with AC power sources 100 - 240 VAC, 50 - 60 Hz.
The power switch is located at the rear of the unit adjacent to the AC power
connector and the system fan. To turn the Switch on, press the power switch
to the on or “1” position. The Switch’s power supply will adjust to the local
power source automatically and may be turned on without having any or all
LAN segment cables connected.
